CARD: general information (4/4)
Fitting a strap 10
Slide the rear casing 8 downwards
while pressing on zone A.
Insert the hand strap into the 11 com-
ponent and pass the end of the strap
through the buckle.
Position the strap at the 9 opening and
close the cartridge.
Note: check that the diameter of the 10
strap cord fits the 9 opening.
Never insert screwdriver-type tools
into the 9 opening.
10
11
8
9
A
