Aérateurs (sorties air) (X82 PH2 - Renault)
Side air vents
Air flow
To close the left-hand side air vent,
slide the tab 11 fully to the right.
To close the right-hand side air vent,
slide the tab 11 fully to the left.
Air flow direction
To direct the air flow, swivel side air
vent 11.
Centre air vents.
Air flow
To close the left-hand central air vent,
slide the tab 9 fully to the left.
To close the right-hand central air vent,
slide the tab 10 fully to the right.
Air flow direction
To direct the air flow, swivel the side air
vent 9 or 10.
AIR VENTS, air outlets (2/2)
11
To remove bad odours from your ve-
hicles, only use the systems designed
for this purpose. Consult an approved
Dealer.
Do not add anything to the
vehicle’s ventilation circuit
(for example, to remove
bad odours).
There is a risk of damage or of
fire.
109
