3.32
ENG_UD75649_4
Rangements, aménagements habitacle (X82 PH2 - Renault)
Tray 22
To unlock the tray, press the control 20.
To install the tray, insert the end
pieces 25 of the tray into the slots 26
or 27.
PASSENGER COMPARTMENT STORAGE SPACE AND FITTINGS (8/10)
You can attach it using the document
grip 28.
To remove the tray, press the con-
trol 29.
Note: make sure you replace the tray
and remove any item from the cup
holder before raising the centre seat
back. Check that the back of the centre
seat is properly locked.
28
22
When turning corners,
accelerating or braking,
ensure that the recepta-
cle being held by the cup
holder is not dislodged.
There is a risk of burning if hot
liquid escapes.
Ensure that no hard, heavy
or pointed objects are
placed in the open storage
compartments in such a
way that they may fall on any pas-
sengers during sudden turning,
braking or in the event of an acci-
dent.
26
27
20
22
25
29
Rear seat storage pockets 30
30
