3.34
ENG_UD75649_4
Rangements, aménagements habitacle (X82 PH2 - Renault)
Use the flap 36 to extend the load
length:
– pull the tab 35 to raise the seat B;
– move the flap 36 towards the interior
of the seat by pulling the tab 37.
PASSENGER COMPARTMENT STORAGE SPACE AND FITTINGS (10/10)
36
Recess 34 and flap 36
Depending on the length of the objects
being transported in the rear load area,
you can use recess 34.
Open the flap 36, held in place by mag-
nets.
36
B
37
Nothing should be placed
on the floor (area in front
of driver) as these objects
may slide under the pedals
during sudden braking manoeuvres,
thus obstructing their use.
Ensure that no hard, heavy
or pointed objects are
placed in the “open” storage
compartments in such a
way that they may fall onto passen-
gers during sudden turning, braking
or in the event of an accident.
34
35
When the flap 36 is open,
use of the front side pas-
senger seat is prohibited.
Risk of serious injury
when braking sharply or in an
impact.
