5.11
ENG_UD72215_2
Changement de roue (X82 PH2 - Renault)
CHANGING A WHEEL (2/2)
Loosen the wheel nuts and remove the
wheel.
Fit the emergency spare wheel in place
on the central hub.
Tighten the nuts and lower the jack.
With the wheels on the ground, tighten
the nuts fully and check if they are tight
as quickly as possible.
Position the trim.
Anti-theft bolt
If you use anti-theft bolts, fit these
nearest the valve (otherwise it may
not be possible to fit the wheel trim).
1
Remove the wheel trim ➥ 5.8.
Use the wheelbrace 1 to slacken off the
wheel bolts. Position it so as to be able
to push from above.
Insert the 2 jack horizontally so that
jack head pin 3 meets the 4 hole in the
lower section of the body and closest to
the wheel concerned.
Begin to crank the jack so that the base-
plate is correctly positioned (it should
be underneath the vehicle and aligned
with the jack head).
4
3
3
2
