Balais d essuie-vitres (X82 PH2 - Renault)
Wipers (replacing blades)
WINDSCREEN WIPER BLADES (1/3)
Windscreen wiper blades 1
With the ignition on and the engine
switched off, lower the windscreen
wiper stalk fully: the wipers stop in a
position away from the bonnet.
1
2
3
Refitting
Offer up the blade 3 of the wiper arm 1
at an angle of 30°.
Slide the blade along the arm until it
clips on. Check that the bonnet is cor-
rectly locked. Lower the windscreen
wiper arm carefully.
With the ignition on, return the wind-
screen wiper stalk to the stop position.
3
1
Lift the windscreen wiper arm 3, press
button 2 to release the blade 1.
1
