Remorquage : dépannage (X82 PH2 - Renault)
TOWING: breakdown (3/3)
Rear towing point 3
(Vehicle without towing equipment)
Rear towing point 4
(Vehicle with towing equipment)
To assemble the towbar ball, please
consult the equipment assembly in-
structions.
Front towing point
Unclip cover 5 by inserting a flat-blade
screwdriver or similar under the cover.
Tighten the towing hitch 6 fully: first
by hand until it stops then finish by lock-
ing it using the wheel brace 7.
Only use the towing eye 6 stored with
the tools ➥ 5.8.
5
6
3
Use only
At the rear:
– for vehicles without towing equip-
ment, towing point 3;
– for vehicles with towing equip-
ment, towing point 4 (towbar ball).
At the front:
– at the front, towing hitch 6 (located
in the tool kit) and the towing point.
4
Ensure that the towing eye
is bolted correctly.
Risk of losing the towed
object.
7
