1.66
ENG_UD73244_2
Sièges enfant : fixation par ceinture de securité (X82 PH2 - Renault)
Two or three-seater van versions
Type of child seat Weight of the child
Front passenger seat(s)
With single
passenger seat
With two-seater bench seat
Centre seat Side seat
Shell seat/rear-facing seat
Groups 0, 0+ and 1
< to 13 kg and 9 to 18 kg U (2) X U (2)
Forward-facing seat
Group 1
9 to 18 kg U (1) X U (1)
Booster seat
Groups 2 and 3
15 to 25 kg and 22 to 36
kg
U (1) X U (1)
X Seat which does not allow a child seat to be fitted.
U Seat which allows a child seat with “Universal” approval to be installed using a seat belt; check that it can be fitted.
(1) Forward-facing child seat; position the seatback of the child seat in contact with the seatback of the vehicle seat. Raise the
headrest. Raise the seat to the maximum and position it as far back as possible, tilting the seatback slightly (approximately
25°).
CHILD SEATS: attachment by seat belt (2/14)
(2) RISK OF DEATH OR SERIOUS INJURY: before fitting a rear-facing child seat in this seat, make sure that the front
passenger airbag has been deactivated ➥ 1.91.
The table below summarises the information already shown on the diagram on the previous page, to ensure the applica-
ble regulations are respected.
