1.70
ENG_UD73244_2
Sièges enfant : fixation par ceinture de securité (X82 PH2 - Renault)
6-seater Combi version
Type of child seat Weight of the child
Front seat Rear seat
Central
passenger
Side
passenger
Side Central
Carrycot fitted across the
vehicle
Group 0
< 10 kg X X U (2) U (2)
Rear-facing shell seat
Groups 0 and 0+
< 13 kg X U (1) U (3) U (3)
Rear-facing seat
Groups 0+ and 1
< 13 kg and 9 to 18 kg X U (1) U (3) U (3)
Forward-facing seat
Group 1
9 to 18 kg X X U (4) U (4)
Booster seat
Groups 2 and 3
15 to 25 kg and 22 to
36 kg
X X U (4) U (4)
CHILD SEATS: attachment by seat belt (6/14)
The table below summarises the information already shown in the diagram on the following pages, to ensure the appli-
cable regulations are respected.
(1) RISK OF DEATH OR SERIOUS INJURY: before fitting a rear-facing child seat in this seat, make sure that the front
passenger airbag has been deactivated. ➥ 1.91.
