Sièges enfant : fixation par système ISOFIX (X82 PH2 - Renault)
CHILD SEATS: attachment using the ISOFIX system (2/12)
5-seater Combi version
Type of child seat Weight of the child
Seat size ISOFIX
[Height]
Front
passenger seat
Rear side
seat
Rear centre
seat
Carrycot fitted across
the vehicle
Group 0
< 10 kg
F, G
[L1, L2]
X IL (1) X
Rear-facing shell seat
Groups 0 and 0+
< 13 kg
E
[R1]
X IL (2) X
Rear-facing seat
Groups 0+ and 1
< 13 kg and 9 to 18 kg
C, D
[R3, R2]
X IL (2) X
Forward-facing seat
Group 1
9 to 18 kg
A, B, B1
[F3, F2, F2X]
X IUF-IL (3) X
Booster seat
Groups 2 and 3
15 to 25 kg and 22 to
36 kg
[B2] X IUF-IL (3) X
Seat I-Size X X X
The table below summarises the information already shown on the diagram on the previous page, to ensure the applica-
ble regulations are respected.
