5.15
ENG_UD65913_2
Fusibles GPL X52 (XBC - Renault)ENG_NU_1321-2_XBC_Renault_5
Number Allocation
A
Defroster/Front power
window
B
Reverse lights/
Front blower (Manual
transmission)
C Day light Running lamps
D Anti-pinch
E Hands free access ECU
F
Rear AC/2nd & 3rd row
Accessory socket
G
Front blower (Automatic
transmission)
H
Power window - Front/
Rear
I Child safety
Number Allocation
1 Rear AC
2 Parking assistance
3 Multimedia CAN interface
4 Not used
5 Child safety
6 Rear power window
7
BCM/Radio/Ultra low cost
navigation
8 Hands-free mode
9 Hands-free mode
10 Not used
11
Starter - Non Hands-free
mode
12 Roof light - Front/Rear
13 Cluster
14 Combi switch
15
Radio/Ultra low cost
navigation
FUSES (3/4)
Number Allocation
16 Combi switch - low beam
17 Body control module
18 Horn
19 Door locking/Tail gate
20 Body control module
21, 22 Not used
23
Electric Outside Rear View
Mirror adjustment
24 Not used
25 Defroster
26 Backup light/Rear wiper
27 Wiper motor
28
BCM/Fuel pump relay/
starter relay/Injection
ECU/Power transmission
control unit/Automatic gear
selector
29 Electric power steering
