child safety: fitting a child seat (XBC - Renault)ENG_NU_1321-2_XBC_Renault_1
CHILD SAFETY: fitting a child seat (2/3)
The table below summarises the information already shown in the diagram on the following pages, to ensure the applicable regu-
lations are respected.
Seating Position
Mass Group
Weight of
the child
Front passenger
seat
Second row seats Third row seats
LEFT RIGHT CENTRE LEFT RIGHT
Group 0 Upto 10 kg X U X X X X
Group 0+ Upto 13 kg X U X X X X
Group I 9 to 18 kg X U X X X X
Group II 15 kg to 25 kg X U X X X X
Group III 22 kg to 36 kg X U X X X X
X = Seat not suitable for fitting child seats.
U = Seat which allows a child seat with “Universal” approval to be installed using a seat belt; check that it can be fitted.
