Reneka International – Instruction of use – Edition 01/2008 – Page 18
TECHNICAL FEATURES
LC (volumetric or ON/OFF)
1 group 2 groups 3 groups
Voltage 230V / 50Hz 230V / 50Hz
230V / 50Hz
400V / 50Hz
Heating element power
(230 V mono)
2100W 3100W 4000W
Heating element power
(400 V 3 phases)
X X 5500W
Max installed power
(230 V mono)
2300W
10,5 Amp
3300W
14,5 Amp
4300W
18,5 Amp
Max installed power
(400 V tri)
X X
5800W
9 Amp / phase
Electrical features
Connection
Line Cord 230
V with plug
Line Cord 230
V with plug
Cable 5x2,5
mm² without
plug
Total boiler volume 5,8 L 10 L 16,5 L
Hot water volume 4,8 L 7,5 L 12 L
Steam volume 1 L 2,5 L 4,5 L
Volumes
Length (mm) 430 650 890
Depth (mm) 500 500 500
Height (mm) 480 480 480
Weight (kg) 40 57 67
Dimensions
Options
2 steam wand No OPTION ON SERIE
Hot water
7L 10L 15L
Flow per
hour
Coffee
120 cups 240 cups 360 cups
