Renesas RA6M Series

Renesas RA Family AIK-RA6M3, v1 User's Manual
R12UZ0143EE0100 Rev.0.1 Page
12
of 25
Oct.15.23
Table 3. JTAG/SWD Connector (J12)
JTAG Connector
AIK-RA6M3
Pin
JTAG Pin Name
SWD Pin Name
Signal/Bus
1
VTref
VTref
+3V3
2
TMS
SWDIO
P101/ (U3-35)
3
GND
GND
GND
4
TCK
SWCLK
P102/ (U3-34)
5
GND
GND
GND
6
TDO
SWO
P100/ (U3-36)
7
Key
Key
N.C.
8
TDI
NC/EXTb
P103/ (U3-33)
9
GNDDetect
GNDDetect
GND (cut E1 to open)
10
RESET
RESET
P112 (U3-29)
The Cortex
®
Debug Connector is fully described in the Arm
®
CoreSight
™
Architecture Specification.
5.2.4.2 Debug Out using Renesas RA4M2 J-Link OB
The AIK-RA6M3 Debug Interface can be configured to use the Renesas RA4M2 to debug a RA6M3 device
on an external board.
A yellow indicator LED4 provides a visual status of the state of the debug interface. When AIK-RA6M3 is
powered on, and LED4 is blinking, this indicates that the Renesas RA4M2 debugger is not connected to a
programming host. When LED4 is on solid, this indicates that the Renesas RA4M2 is connected to a
programming interface.
