RL78/G13 Clock Generator (Clock Switching) CC-RL
R01AN2831EJ0100 Rev. 1.00 Page 6 of 51
May 28, 2015
2. Operation Check Conditions
The sample code contained in this application note has been checked under the conditions listed in the table below.
Table 2.1 Operation Check Conditions
Item Description
Microcontroller used RL78/G13 (R5F100LEA)
Operating frequency CPU/peripheral hardware clock:
Switches the operating clock when the switch on the target board is pressed.
When the HOCO clock is selected: 32 MHz
When the X1 oscillation clock is selected: 20 MHz
When the XT1 oscillation clock is selected: 32.768 kHz
Operating voltage 5.0 V (can run on a voltage range of 2.9 V to 5.5 V.)
LVD operation (V
LVD
): Reset mode 2.81 V (2.76 V to 2.87 V)
Integrated development
environment (CS+)
CS + V3.01.00 from Renesas Electronics Corp.
C compiler (CS+) CC-RL V1.01.00 from Renesas Electronics Corp.
Integrated development
environment (e
2
studio)
e
2
studio + V4.0.0.26 from Renesas Electronics Corp.
C compiler (e
2
studio) CC-RL V1.01.00 from Renesas Electronics Corp.
Board used RL78/G13 target board (QB-R5F100LE-TB)
3. Related Application Note
The application note that is related to this application note is listed below for reference.
RL78/G13 Initialization (R01AN2575E) Application Note
To Next Page
