RL78/G13 Safety Function (Frequency Detection)
R01AN0956EJ0100 Rev. 1.00 Page 11 of 70
Feb. 27, 2012
5.3 List of Option Byte Settings
Table 5.2 summarizes the settings of the option bytes.
Table 5.2 Option Byte Settings
Address Value Description
000C0H/010C0H 11101111B Disables the watchdog timer.
(Stops counting after the release from the reset status.)
000C1H/010C1H 01111111B LVD reset mode, 2.81 V (2.76 V to 2.87 V)
000C2H/010C2H 11101000B HS mode, HOCO : 32 MHz
000C3H/010C3H 10000100B Enables the on-chip debugger.
Erases the data in the flash memory when on-chip debugging security ID
authentication fails.
