Renesas RL78 Series Application Note

RL78 Family VDE Certified IEC60730/60335 Self Test Library
R01AN0749EG0201 Rev.2.01 Page 31 of 50
Mar 04, 2014
4 Benchmarking
4.1 Development Environment
• IECUBE - QB-RL78G13-ZZZ-EE Full RL78/G13 In circuit Emulator
• QB-R5F100LE-TB RL78/G13 Target Board 64pin LQFP (10 x 10mm)
• Tool chain: IAR Embedded Workbench Version 1.20.1
MCU: R5F100LE (64KB Flash, 4KB RAM 64pin)
Internal Clock: 32 MHz High Speed Oscillator
System Clock = 32 MHz
External Sub Clock: 32 KHz
4.2 IAR Embedded Workbench Settings
The following show the specific options and setting set for the test harness project. The graphics only show those
options and settings that have been changed. All others are the default project settings set by the IAR Embedded
Workbench.
4.2.1 General Options
Figure 10 IAR EW General Options - Target Device
