Renesas RL78 Series Application Note

RL78 Family VDE Certified IEC60730/60335 Self Test Library
R01AN0749EG0201 Rev.2.01 Page 38 of 50
Mar 04, 2014
5 Resources
The following resource tables include only the resources and execution times needed for the self test modules. The
figures do not include data for the test harness files.
All timings are based on the following environment settings
MCU: R5F100LE (64KB Flash, 4KB RAM, 64 pin)
Internal Clock: 32 MHz High Speed Oscillator
System Clock = 32 MHz
External Sub Clock: 32 KHz
3.1 CPU Register Tests
Note: Optimisation should not be used for these tests.
3.1.1 Working Registers Test
Table 16: Working registers Resources
Measurement
Code size 178B
Stack usage (Module use plus function call) 12B
Data 1B
Execution time
320 cycles
10uS
3.1.2 PSW Register Test
Table 17: PSW Registers Resources
Measurement
Code size 43B
Stack usage (Module use plus function call) 6B
Data 1B
Execution time
32 cycles
1uS
