Renesas RZ/T2M Hardware Manual

RZ/T2M Group RZ/T2M Motor Solution Board Hardware Manual
R01AN5986EJ0100 Rev.1.00 Page 12 of 30
Jul.31.21
Table 3.4 Inverter board switch function
No
SW
Item
Content
Default
1
SW1
In case of abnormality + 24V cut off switch
ON(Up): 24V ON/ OFF(Down): 24VCut off
ON(Up)
3.2.1.1 Selection of operation mode
The operation mode supported by this board is xSPI0 boot mode (x1 boot Serial flash) only (MD0 to MD2: All
low settings).
Table 3.5 is shown the SW1500 setting.
Table 3.5 SW1500 Setting
1
2
3
4
5
6
7
8
9
10
OFF
ON
OFF
ON
OFF
ON
OFF
ON
ON
OFF
Select the operation mode before turning on the power.
