Renesas RZ/T2M Hardware Manual

RZ/T2M Group RZ/T2M Motor Solution Board Hardware Manual
R01AN5986EJ0100 Rev.1.00 Page 26 of 30
Jul.31.21
5. Detection circuit
Table 5.1 is shown the current and voltage detection circuits mounted on the inverter board and the RZ /
T2M connection destinations.
Table 5.1 List of detection circuits
No
Circuit
Pin Number
Function
Circuit diagram silk name
1
Overcurrent detection circuit
H5
IRQ3-A
POE_FOV_RZ
F18
IRQ2-C
POE_FOV2_RZ
2
Current detection circuit 1
(Current Transducer)
B17
AN000
AD_IU1_RZ
C16
AN001
AD_IV1_RZ
A18
AN002
AD_IW1_RZ
F13
AN100
AD_IU2_RZ
B16
AN101
AD_IV2_RZ
E13
AN102
AD_IW2_RZ
3
Current detection circuit 1
(ΔΣ modulator)
G5
MDAT0
DSM_MDAT0_RZ
G6
MCLK0
DSM_MCLK0_RZ
A6
MDAT1
DSM_MDAT1_RZ
E3
MCLK1
DSM_MCLK1_RZ
E9
MDAT2
DSM_MDAT2_RZ
K2
MCLK2
DSM_MCLK2_RZ
B6
MDAT3
DSM_MDAT3_RZ
M6
MCLK3
DSM_MCLK3_RZ
C4
MDAT4
DSM_MDAT4_RZ
B3
MCLK4
DSM_MCLK4_RZ
P15
MDAT5
DSM_MDAT5_RZ
C3
MCLK5
DSM_MCLK5_RZ
4
Busbar voltage detection circuit
(24V)
E16
AN003
AD_BUS1_RZ
A17
AN103
AD_BUS2_RZ
