INSTRUCTION MANUAL | HARDWIRED LED ILLUMINATED MIRROR | ENGLISH | 3
A. Lay mirror carefully with mirror facing down flat and remove the
back plate of the LED illuminated mirror (Fig 1A). Be sure to
disconnect the sensor switch wire prior to completely separating
the mirror from the back plate. Separate the back plate from the
mirror (Fig.1B).
B. Place the back plate over the area where the illuminated mirror
will be installed and draw in the holes. Ensure the unit is level
before marking your holes (Fig.2).
MAPPING OUT THE MIRROR BACK
PLATE INSTALLATION AREA
1
Use level
Mark installation holes
Fig.1A
Fig.2
PART# 98-3200 REV.B
Separate the back plate from the mirror
Fig.1B
Disconnect
Models:
Model:
200097, 200158, 200169,
200170, 200156, 200157
200155
To Next Page
