Renishaw RMI-Q User Manual

1-5
Abbreviations are as follows:
• N.O. = Normally Open
• N.C. = Normally Closed
• N.H. = Normally High
• N.L. = Normally Low
Factory settings shown are for:
• A-5687-0050
Switch settings SW1 and SW2
Switch SW1 output configuration Switch SW2 output configuration
SW1
SW2
Dedicated Seated ‘Fast’
start start on turn on
PROBE MACHINE
STATUS 2a/2b START
ON
Pulsed N.O. N.O. N.O. Pulsed N.H. Level
PROBE LOW ERROR
STATUS 1 BATTERY
Level N.C. N.C. N.C.
Level N.L. Pulsed Common Seated ‘Standard’
start start off turn on
