(1) Left loudspeaker (18) SD card reader
(2) CD/USB/SD button (19) ALBUM/PRESET button F
(3) IR sensor (20) ALBUM/PRESET button S
(4) STANDBY indicator (21) CD drawer
(5) PHONO button (22) AUX IN connector
(6) TUNER/BAND button (23) TUNING/SKIP knob
(7) AUX button (24) Cover
(8) TIMER/SLEEP button (25) FM wire aerial
(9) OPEN/CLOSE button (26) LINE OUT R connector
(10) Right loudspeaker (27) Power adapter connector
(11) VOLUME/POWER knob (28) LINE OUT L connector
(12) Headphones connector (29) Single puck
(13) REC/DEL button (30) Pick-up lift
(14) MODE/CLK button (31) AUTO STOP ON/OFF switch
(15) USB interface (32) 33/45/78 button
(16) SCAN button (33) Pick-up
(17) H button
