RENNTECH AIXRO XR50 User Manual

8
ASSEMBLY PROCEDURES
(continued)
3.8
STARTER
The standard XR50 engine is started using an external starter placed over the clutch fastening
nut (with a 22 mm socket) or started with an optional on-board starter.
3.8.1
OPTIONAL ON-BOARD STARTER
RENNtech’s optional on-board starter is intended for use in short start intervals. Under normal
conditions, the motor should crank and start almost immediately.
3.8.4
ELECTRICAL CONNECTION
The optional starter motor is a 12V system, controlled via relay.
ATTN: DO NOT CRANK MOTOR USING STARTER FOR MORE THAN 10 CONSECUTIVE SECs.
!TIP: on-board starter should not be used for initial start-up during break-in period. External
starter is recommended until engine “loosens up” and starts easily.
!TIP: check all positive connectors and shield against accidental grounding.
3.8.2
EXTERNAL (or “REMOTE”) STARTER
ATTN: DO NOT CRANK MOTOR USING STARTER FOR MORE THAN 10 CONSECUTIVE SECs.
!TIP: once the engine starts, remove the starter socket IMMEDIATELY to avoid nut loosening.
!TIP: check central nut for tightness after each run when external starter is used.
!TIP: complete COLEMAN starters available through RENNtech INC.
RENNTECH / AIXRO XR50 ENGINE OPERATOR MANUAL
