— 06 —
EN
How to connect COMPACT-SUITCASE in series/parallel
z
To expand the power output, COMPACT-SUITCASE can be connected either in series or
parallel.
z
Connect COMPACT-SUITCASE in series.
z
Connect COMPACT-SUITCASE in parallel.
