Reolink Argus 3 Pro Operational Instruction

USB
ON
OFF
MicroSD
RST
Camera Introduction
Battery Status LED
Set up the Camera using a Smartphone
Red Light: WiFi connection failed
Blue Light: WiFi connection succeeded
Blinking: Standby status
On: Working status
Set up the Camera
NOTE: Always keep the rubber plug closed firmly.
Speaker
Spotlight
Lens
Daylight Sensor
Reset Button
Dierent states of the status LED:
Status LED
Built-in Mic
PIR Motion Sensor
Power Switch
Micro SD Card Slot
* Press for more than five seconds to reset
the device to factory settings.
Micro USB Power Port
Step 1 Scan to download the Reolink App from the App Store or Google Play store.
Step 2 Turn on the power switch to power on the camera.
EnglishEnglish
ON
MicroSD
MicroSD
Switch
ON
MicroSD
3 4

Reolink Argus 3 Pro Specifications

General

Type	IP security camera
Luminous flux	230 lm
Day/night mode	Yes
Color temperature	6500 K
Placement supported	Outdoor
Connectivity technology	Wireless
Form factor	-
Mounting type	Ceiling/wall
Product color	White
LED indicators	Status
International Protection (IP) code	IP65
Sensor type	CMOS
Optical sensor size	1/3 \
LED type	IR
Infra-red wavelength	850 nm
Night vision distance	10 m
Number of illumination LEDs	6
Total megapixels	4 MP
Maximum resolution	2560 x 1440 pixels
Video formats supported	H.265
Number of cameras	1
Field of view (FOV) angle	122 °
Digital zoom	16 x
Audio system	2-way
Security algorithms	WPA-PSK, WPA2-PSK
Alert notification type	E-mail, Text alert message
Motion sensor technology	Passive infrared (PIR) sensor
Intelligent Video Surveillance (IVS) system features	Human detection
Ethernet LAN	No
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Power source type	Battery, USB
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	128 GB
Operating temperature (T-T)	-10 - 55 °C

Weight and Dimensions

Depth	121 mm
Width	56 mm
Height	90 mm
Weight	330 g
