Reolink Argus PT Quick Start Guide

English English7 8
Install the Camera
• The camera MUST be
installed upside down for better
waterproof performance and
better PIR motion sensor’s
eciency.
• Install the camera 2-3 meters
(7-10 ft) above the ground. This
height maximizes the detection
range of the PIR motion sensor.
• For better motion detection
performance, please install the
camera angularly.
Notes on Camera
Installation Position
Mount the Camera
Drill holes in accordance with the
mounting hole template and screw the
camera bracket to the wall.
NOTE: Use the drywall anchors included in the package if needed.
Install the antenna to the camera.
1
2
NOTE: If a moving object approaches the
PIR sensor vertically, the camera may fail
to detect motion.

Reolink Argus PT Specifications

General

Type	IP security camera
Antenna type	External
Remote viewing	Yes
Antennas quantity	1
Placement supported	Indoor
Connectivity technology	Wireless
Bluetooth	No
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	64 GB
Sensor type	CMOS
Digital zoom	6 x
Total megapixels	- MP
Maximum resolution	- pixels
Supported video modes	1080p
Video compression formats	H.264
Cables included	Micro-USB
Pan range	0 - 355 °
Tilt angle range	0 - 140 °
Minimum illumination	- lx
Night vision distance	10 m
Security algorithms	WEP, WPA-PSK, WPA2-PSK
Alert notification type	E-mail
Motion sensor technology	Passive infrared (PIR) sensor
DC output current	2 A
DC output voltage	5
Power source type	Battery, DC
Operating temperature (T-T)	-10 - 55 °C
Form factor	Dome
Mounting type	Ceiling/wall
Product color	White
International Protection (IP) code	IP65

Weight and Dimensions

Height	112 mm
Weight	470 g
Diameter	98 mm
