Connection Diagram
Camera Introduction
Before using the camera, please connect your camera as instructed
below to finish initial setup.
1. Connect the camera to a Reolink NVR (not included) with an Ethernet cable.
2. Connect the NVR to your router, and then power on the NVR.
* You may also connect the camera to a PoE switch or PoE injector.
NOTE: The camera should be powered with a 12V DC adapter or a PoE powering device such as
PoE injector, PoE switch or Reolink NVR (not included in the package).
PoE IP Camera
Ethernet Cable
Reolink NVR
Router
Power Adapter
Micro SD Card Slot
Mount
Spotlight
Lens
Built-in Mic
Speaker
Waterproof Lid
Network Cable
Reset Button
* Press for about 10 seconds to
restore the device to factory settings.
Power Port (Optional)
