Reolink E1 Pro User Manual

E1 Pro
Set up the Camera on the App
There are two methods to do the initial setup of the camera:
1. with a Wi-Fi connection; 2. with a network cable connection.
1. With Wi-Fi Connection
Step 1. Tap the icon in the top right corner to add the camera.
Mounting Template *1
Surveillance Sticker*1
Pack of Screws*1
Reset Needle*1
E1 Pro*1
Quick Start Guide*1
Mounting Plate *1
Power Adapter*1

Reolink E1 Pro Specifications

General

Sensor type	CMOS
Number of sensors	1
Optical sensor size	1/2.7 \
Type	IP security camera
Placement supported	Indoor & outdoor
Connectivity technology	Wireless
Maximum operating distance	12 m
Infrared (IR) cut-off filter	Yes
Total megapixels	4 MP
Maximum resolution	2560 x 1440 pixels
Video compression formats	H.264
Pan range	355 - 30 °
Minimum illumination	0 lx
DC output current	1 A
DC output voltage	5
Power source type	DC
Built-in HDD	No
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	128 GB
Audio system	2-way
Ethernet LAN	-
Number of users	20 user(s)
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n)
User access level	Administrator, User
Supported network protocols	SSL, TCP/IP, UDP, IPv4, UPnP, RTSP, SMTP, NTP, DHCP, DNS, DDNS, P2P
Mac operating systems supported	macOS
Mobile operating systems supported	Android, iOS
Security algorithms	WPA-PSK, WPA2-PSK
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-10 - 55 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 85 %
Form factor	Turret
Mounting type	Desk
Product color	White
Harmonized System (HS) code	85258900

Weight and Dimensions

Length	106 mm
Weight	200 g
Diameter	76 mm
