Reolink NVS8 - NVR Introduction

English English3 4
NVR Introduction
Power LED: Solid green to indicate the NVR is powered on.
HDD LED: Flashing red to indicate the hard drive is operating properly.
NOTE: Quantity and appearance of devices and accessories vary by dierent models that you
purchase.
Mount the Camera to the Ceiling
USB PORT
HDMI Port
Power Input
HDD LED
PoE Ports
USB Port
Power LED
LAN Port
Audio Out
Power Switch
VGA Port
1
9
5
3
11
7
2
10
6
4
8
Model: NVS16
USB PORT
HDMI Port
Power Input
HDD LED
USB Port
PoE Ports
eSATA Port
Power LED
LAN Port
Audio Out
Power Switch
VGA Port
1
9
5
3
11
12
7
2
10
6
4
8
Model: NVS8
