Page #6 background image
Camera Is Not Powering on
If your camera is not powering on, please try the following solutions:
• Make sure your camera is powered on properly. The PoE camera
should be powered by a PoE switch/injector, a Reolink NVR or a 12V
power adapter.
• If the camera is connected to a PoE device as listed above, connect the
camera to another PoE port and see if the camera will power on.
• Try again with another Ethernet cable.
If these won’t work, contact Reolink Support https://support.reolink.com/.
Troubleshooting
Infrared LEDs Stop Working
If the Infrared LEDs on your camera stop working, please try
the following solutions:
• Enable infrared lights on Device Settings page via Reolink App/Client.
• Check if the Day/Night mode is enabled and set up auto infrared lights
at night on Live View page via Reolink App/Client.
• Upgrade the firmware of your camera to the latest version.
• Restore the camera to factory settings and check out the infrared light
settings again.
Specifications
Operating Temperature: -10°C to 55°C (14°F to 131°F)
Operating Humidity: 10%-90%
Ingress Protection: IP66
Night Vision: 60 meters (190ft)
Day/Night Mode: Auto switchover
Angle of View: Horizontal: 87°~31°, vertical: 65°~24°
Hardware Features
General
If these won't work, contact Reolink Support https://support.reolink.com/.
Failed to Upgrade the Firmware
If you cannot upgrade firmware for the camera, try the following
solutions:
• Check out the current camera firmware and see if it is the latest one.
• Make sure that you download the correct firmware from Download
Center.
• Make sure that your PC is working on a stable network.
If these won't work, contact Reolink Support https://support.reolink.com/.
10English
9 English

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Reolink RLC-423 and is the answer not in the manual?

Reolink RLC-423 Specifications

General IconGeneral
TypeIP security camera
Day/night modeYes
Placement supportedOutdoor
Connectivity technologyWired
Sensor typeCMOS
Number of sensors1
Optical sensor size1/2.7 \
FocusMotorized
Optical zoom4 x
Focal length range2.7 - 12 mm
Maximum aperture number1.6
Total megapixels5 MP
Maximum resolution2560 x 1920 pixels
Video compression formatsH.264
Noise reduction technology3D noise reduction
Supported graphics resolutions640 x 480 (VGA), 2048 x 1536 (QXGA), 2304 x 1296, 2560 x 1440, 2560 x 1920
Cables includedLAN (RJ-45)
Pan range0 - 360 °
Pan speed180 °/sec
Tilt angle range0 - 90 °
Minimum illumination0 lx
Wi-FiNo
Number of users20 user(s)
Networking standardsIEEE 802.3at
Ethernet interface typeFast Ethernet
Supported network protocolsHTTPS, SSL, TCP/IP, UDP, UPNP, RTSP, SMTP, NTP, DHCP, DNS, DDNS, FTP, P2P
Compatible memory cardsMicroSD (TransFlash)
LED typeIR
Night vision distance60 m
Number of illumination LEDs6
Audio input channels1 channels
Mobile operating systems supportedAndroid, iOS
DC output voltage12
Power source typeDC, PoE
Power consumption (max)20 W
Operating temperature (T-T)-10 - 55 °C
Operating relative humidity (H-H)10 - 90 %
Form factorDome
Mounting typeCeiling/wall
Product colorWhite
Housing materialAluminum
International Protection (IP) codeIP66
Weight and Dimensions IconWeight and Dimensions
Height201 mm
Weight1700 g
Diameter136 mm
