Reolink RLC-510A User Manual

Reolink PoE Camera
User Manual
17
Audio
Enable audio
Manually capture
Manually record
Manually recording
Live view in sub-stream mode
Live view in main stream
mode
View your camera in a full-screen mode.
Talk: Tap to talk (two-way audio).
Clip: Drag the rectangle to the position you want to see.
PTZ: Control pan,tilt or zoom.
Playback: Replay the recordings saved to the SD card.
Channel Selection
You can choose the devices you want on the device list.

Reolink RLC-510A Specifications

General

Form factor	Bullet
Weatherproof	Yes
Mounting type	Ceiling/wall
Product color	White
Housing material	Aluminum
International Protection (IP) code	IP66
Sensor type	CMOS
Number of sensors	-
Optical sensor size	1/2.7 \
Type	IP security camera
Placement supported	Indoor & outdoor
Connectivity technology	Wired
Number of lenses	1
LED type	IR
Infra-red wavelength	850 nm
Night vision distance	30 m
Number of illumination LEDs	18
Total megapixels	5 MP
Maximum resolution	2560 x 1920 pixels
Video formats supported	H.264
Minimum illumination	- lx
DC output current	1 A
DC output voltage	12
Power source type	DC, PoE
Power consumption (typical)	12 W
Wi-Fi	No
Number of users	20 user(s)
Networking standards	IEEE 802.3af
Ethernet interface type	10 Gigabit Ethernet, 100 Gigabit Ethernet
Supported network protocols	HTTPS, SSL, TCP/IP, UDP, HTTP, IPv4, UPnP, RTSP, RTMP, SMTP, NTP, DHCP, DNS, DDNS, FTP, P2P
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	256 GB
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %
Mobile operating systems supported	Android, iOS

Weight and Dimensions

Depth	186 mm
Height	67 mm
Weight	425 g
