Reolink RLC-810A User Manual

Stien the adjustment knob to
lock the camera.
Drill holes in accordance with the
mounting hole template.
NOTE: There are two dierent types of mounts for bullet cameras.
Please check out the mount included in the package and follow the
corresponding instruction to install the camera properly.
NOTE: Use the drywall anchors
included in the package if needed.
NOTE: Run the cable through the
cable notch on the mount base.
Install the mount base with the
mounting screws included in
the package.
To get the best field of view,
loosen the adjustment knob
on security mount and turn
the camera.
Install the Camera
10English9 English
1
2
3
4

Reolink RLC-810A Specifications

General

Type	IP security camera
Day/night mode	Yes
Placement supported	Indoor & outdoor
Connectivity technology	Wired
Form factor	Bullet
Mounting type	Ceiling/wall
Product color	White
Housing material	Aluminum
International Protection (IP) code	IP66
Built-in HDD	No
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	256 GB
DC output current	1 A
DC output voltage	12
Power source type	DC, PoE
Number of users	20 user(s)
Networking standards	IEEE 802.3af
Supported network protocols	HTTPS, SSL, TCP/IP, UDP, HTTP, IPv4, UPnP, RTSP, RTMP, SMTP, NTP, DHCP, DNS, DDNS, FTP, P2P
Ethernet LAN (RJ-45) ports	1
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %
Sensor type	CMOS
Number of sensors	-
Optical sensor size	1/2.49 \
Minimum illumination	- lx
LED type	IR
Infra-red wavelength	850 nm
Night vision distance	30 m
Number of illumination LEDs	18
Total megapixels	8 MP
Maximum resolution	3840 x 2160 pixels
Video formats supported	H.265
Mobile operating systems supported	Android, iOS

Weight and Dimensions

Depth	196 mm
Height	66 mm
Weight	485 g
