REP FT-3000 - Install Weight Stacks; Route Cables and Attach Ends; Attach Curtains; Attach Shrouds and Attachments

5.
Attach curtains.
6.
Start by screwing in the end of the cable to its starting point on
the pulley carriage. Feed the cable through the pulley system (it
may help to remove some of the pulleys to aid in feeding the
cable through) and attach the ball and carabiner to the end.
x16
x16
(M8x20)
x4
x4
x4
x2
(M8x30)
x2
4.
Slide weight stack onto the poles (padded side facing
up) and secure at the top.
Attach shrouds, weight pins and any attachments.
7.
Denver, CO
This step is optional as
it is not neccessary
for safe operation.
Any issues? Please contact us directly by phone: 720-420-1731, email: info@repfitness.com or
morse code...(.-. . .--. ..-. .. - -. . … …). We are always here for our Customers! - Team REP
x12
x12
(M8x20)
