Swift FX
Disassembly
Refer to the Swift FX disassembly illustrations in this user guide.
Disassembly steps
1–2. Remove the headgear by slightly twisting each headgear arm
and pulling away from the node on the pillows.
3–4. Gently push the swivel ring up and pull out of the cushion.
Reassembling
Refer to the Swift FX reassembly illustrations in this user guide.
Reassembly steps
1–2. Insert the swivel ring into the opening of the cushion. Ensure
that the cushion sits between the ridges of the swivel ring.
3. Rotate the elbow to ensure it moves freely.
4. Check that the inner walls of the nasal pillows are not
compressed or collapsed. If so, squeeze each nasal pillow to
release the inner wall.
5. Thread the headgear strap through the top buckle.
6. Hold the headgear arm with the recess facing you. Latch the
headgear arm onto the node on the pillows.
7. Repeat step 6 with the other headgear arm.
8–9. Thread the back strap through each side of the headgear,
then fold over to secure. Ensure that the hook tab is on the
outside.
