Retevis RB85 - Specification

Specification
General
Channel Capacity
Operating Voltage
Operating Temperature
Antenna
Antenna Impedance
Power
16 channels
7.4VDC
-10℃~+50℃
High gain antenna
50Ω
10W/5W
Transmitter
Modulation Type
Spurious Radiation
Modulated noise
Modulation distortion
Frequency stability
Max Fr. Deviation
Audio response(300-3000Hz)
Adjacent CH. Power
Intermediation sensitivity
16KFΦ3E
≤7.5
μ
V
<-40dB
<5%
5ppm
≤ ±5KHz
+6.5~ -14dB
≥65dB
8-12mv
Receiver
Sensitivity
Occupied bandwidth
Selectivity
Intermediation
Audio Output
Audio Distortion
Frequency Stability
current
Audio response(300-3000Hz)
≤0.2μV
≤16KHz
≥65dB
≥55dB
> 1W
≤5%
5ppm
55mA(when standby);150mA(when working)
+7~ -12.5dB
Note: Specification will be revised without notice due to technical improvement. Thank you.
7
