Retroactive GBS-8100 - Gbs-8100 V2 Wiring Diagram

5 PIN CGA/RGBS OUTPUT
VGA INPUT
COMPOSITE VIDEO OUT
BARREL JACK 5V DC IN
TWO PIN 5V DC IN
SCREEN POSITION ADJUSTMENT BUTTONS
RIGHTUPDOWN LEFT MENU
S-VIDEO OUT
VGA OUTPUT
VGA to CGA Converter
GBS-8100 Ver. 2
Wiring Diagram
Page 4
