7. SPECIFICATIONS & DETAILED DISPLAY FUNCTIONS
A. Power
DC 5V 2A +/- 0.5V
B. CGA/EGA
14.5V - 16.5K
23.5V - 25.5K
30.5V - 32.5K
AUTO SCAN
C. RGBHV
30.5V - 32.5K
AUTO SCAN
D. VGA
30.5V - 32.5K
AUTO SCAN
E. YPBPR
480i, 576i, 720i, 1080i
AUTO SCAN
F. INPUT SIGNAL
YCBCR
480i, 576i, 720i, 1080i
AUTO SCAN
G. OUTPUT SIGNAL
VGA
640x480, 800x600, 1024x768, 1360x768
H. USER CONTROL
Input Switch, Image Zoom, Image Position
Output Resolution R/G/B gain adjust.
Menu Key
R/G/B
I. DIMENSIONS: 115x105x20mm (4.5” x 4.13” x 0.75”) (Some models may vary.)
VGA to CGA Converter
GBS-8100 Ver. 2
Page 6
