Technical specifications
Machine designation: BB 200
Utilization in accordance with the intended purpose
The BB 200 is suitable for reducing medium-hard to very-hard
substances as well as for brittle and tough materials.
The ultimate fineness can be as little as 2 mm and, depending on
the material being processed, may be even less.
The following is a list of some of the materials which can be
ground using the BB 200:
Bakelite // bauxite // concrete // dolomite // ores // feldspar
// granite // graywacke // glass // limestone // gravel // coal
// coke // corundum // quartz // salts // refractory clay //
slag // silicates // silicon // sintered materials // cement
clinker, etc.
Do not make any modifications to the machine and use only RETSCH
approved spares and accessories.
Failure to comply will invalidate the CE declaration and guarantee.
Gap width adjustment range
From 0 to about 30 mm using a threaded spindle
Throughput rate and ultimate fineness
The performance data, through-put rate and attainable ultimate
fineness are dependent on the fracturing properties and the
hardness of the product being ground. These values can only be
determined empirically.
Receiver drawer volume
approx. 5 dm
3
Noise emissions
Noise level at a distance of 1m:
approx. 63 dB (A) when idling
The noise level can rise depending on the product being
processed.
Electrical protection class
IP54
Rated power
1500 Watt
