Detachable
Wand Rest
SOME ASSEMBLY REQUIRED
For additional assembly instructions, please see the operating manual.
ATTACHING THE HOSE
Before attaching the Filter Panel to the Base,
ensure the Mesh Filter Basket is properly
aligned and in place.
ATTACHING THE WAND
While holding the Wand in
one hand and the Hose in
the other, align the Key on
the Hose with the Groove on
the Wand.
Insert the Key into the Wand
base. Turn the Strain Relief
clockwise until the lock
symbol and arrow align.
WAND REST
The interchangeable
Wand Rest can be
installed on either side of
the Base.
Slide the at clip into
the Base until it locks
into place.
Insert the bottom Filter Panel Tab into the
Groove located at the bottom of the Base. Push
the Filter Panel forward rmly until it is ush with
the Base opening. Turn the Filter Panel Latch
clockwise to lock the Filter Panel into the Base.
1. 2.
Wand
Neck
Strain
Relief
scan to launch
assembly videos
Key
