Revox G36 - Page 51

INDEX ORDER
N°
PART DESCRIPTION SERIES Qu Ind
III
I II III
F
Amplifier - Chassis
01 59.12.0103 Electrolyte Condensor 3 x 50 µF 350 V x x x 2 7163
02 59.12.0106 Electrolyte Condensor 3 x 600 µF 35 V x x x 1 7164
03 70.01.0131 Rectifier B 30 C 1000 / 600 Sealed x x x 1 7165
04 70.01.0102 Rectifier B 250 C 100 x 1 7166
04 70.01.0161 Rectifier B 250 C 100 Sealed x x 1 7167
05 70.01.0121 Rectifier B 30 C 250 x x x 1 7168
06 1.736.648 Mains Transformer 50 Hz x x x 1 7169
06 1.736.654 Mains Transformer 60 Hz x x 1 7170
06 1.736.650 Mains Transformer Semko x x x 1 7171
07 1.736.660 Output Transformer x x x 1 7172
09 1.736.680 Bias Oscillator Complete (less valve) x x x 1 7173
10 1.736.682 Oscillator Coil T 854, Less Ferrite Housing x x x 1 7174
Check serial n° of recorder:
1.736.681 Bias Oscillator Complete 2-Track N° 69701 and
above and for 60101 – 60700 & 63101 - 68500
x 1
1.736.689 Bias Oscillator Complete 4-Track N° 69701 and
above and for 60101 – 60700 & 63101 - 68500
x 1
1.736.683 Bias Oscillator Complete T 854 N° 69701 and above
and for 60101 – 60700 & 63101 - 68500
x 1
61.01.0163 Oscillator Coil Housing x x x 2 7175
11 58.20.1104 Potentiometer 100k (P 10 + P 11) Bias Adjust x x x 2 7176
59.16.0122 Trimmer Condenser 20 – 150 pF, Bias Oscillator x x x 1 7177
12 1.736.480 Equaliser Panel (Printed Circuit Complete) Incl.
Trimm-pot meter and VU-meter amplifier 2-Track
50 Hz
x x x 1 7178
12 1.736.486 Equaliser Panel Complete 2-Track 60Hz NAB x x x 1
12 1.736.481 Equaliser Panel Complete 4-Track 50Hz x x x 1
12 1.736.487 Equaliser Panel Complete 4-Track 60Hz NAB x x x 1
12 1.736.491 Equaliser Panel Complete 2-Track 7.5/15 ips 50Hz x x x 1
13 58.20.0504 Trimm-Pot Meter 500K VU-Meter Amplifier x x x 2 7180
14 58.20.0104 Trimm-Pot Meter 100K, Cross-talk Comp. x 1 7181
15 1.736.686 Coil, Dummy Head Load T856 x x x 1 7182
15 1.736.687 Coil, Dummy Head Load T 856 2-Track N° 69701
and above and for 60101 – 60700 & 63101 - 68500
x 1
15 1.736.688 Coil, Dummy Head Load T 856 4-Track N° 69701
and above and for 60101 – 60700 & 63101 - 68500
x 1
16 1.736.684 Bias Rejection Filter, Record T 855 x x x 2 7183
17 1.736.720 Bias Rejection Filter, Playback T 899 Complete with
Two Coils (L3 + L4)
x x x 1 7184
1.736.595-03 Switch Wafer (S2) Monitor Selector x x x 1 7185
18 1.736.400-09 Potentiometer (P2) 220 K Monitor Volume x x x 1 7186
1.736.695-04 Switch Positioner, Monitor Selector x x x 1 7187
19 1.736.400-09 Potentiometer (P1) 220 K, Bass Control x x x 1 7188
1.736.700-01 Switch Wafer (S3, S4) Input Selector x x x 2 7189
1.736.700-02 Switch Positioner, Input Selector (S3, S4) x x x 2 7190
20 1.736.400-12 Potentiometer (P3, P4) 100 K Record Level x x x 2 7191
08 55.01.0101 Mains Switch x x x 1 7192
1.736.863 Outer Shaft Extension Complete for Mains Switch x x x 1 7205
1.736.870 Outer Shaft Extension Complete for Input Selector
Ch I
x x x 1 7206
1.736.875 Outer Shaft Extension Complete for Input Selector
Ch II
x x x 1 7207
