Page 10 of 55
ILLUSTRATED PARTS MANUAL:
FLOWLINE COMB & WIRE
BINDER RANGE
D55200 Fixed Spindle 2
D55202 Rubber Foot - L Shaped 2
D55203 Rubber Foot - Front 2
D55213 Punch Switch Insulation collar 1
D55214 Tie Bar 1
D55215 Compound Gear 26/10T 1
D55218 Tie Rod Bush 2
D55219 Motor insulator 1
D55220 Gear Box end plate 1
D55226 Wire - cap to PCB 1
D55229 Push Plate 1
D55236 Gear Box Shaft Retainer 1 See Issue 3
D55240 Compound Gear 41/10T (Sintered) 1 See Issue 12
D55241 Compound Gear 41/10T (Metal) 1 From S/No A678191 to A710068 See Issues 5 and 12
D55242 Thermal Fuse Assembly 1 From S/No A670764 to A694089 See Issues 4 and 11
PEG93 6 x 50mm heavy duty spirol pin 3
PEG95 1/8 x 3/8" medium duty spirol 21
PLN2L 3BA plain washer 4
PLN29 M5 plain washer 1 From S/No A678191 to A710068 See Issues 5 and 12
PLN37 M9 Shim Washer 1
RTS73 Rivet 3
SCM157 M6 x 20 Taptite 4
SCM158 M5 x 16 Taptite 2
SCM159 M6 x 50 Taptite 3
SCM160 M4 x 12 Taptite 6
SCM162 M4 x 10 Screw 3
SCR718 M4 x 10 Plasform 1 Pozi Pan Screw 2 See Issue 6
SCR720 M3.5 x 10 plastech 9
SCR71 M2.5 x 8 Screw 2
SCR722 M5 x 16 Plasfix Screw 8
SCR724 M3 x 8 Screw 6
SCR725 M5 x 20 Screw 7
SHK2 3BA Shakeproof Washer 2
SL17-144 Cable Tie 6
SL17-300 Binder motor PCB 1 To S/No A717392 – See Issue 14
SL17-301 Binder LED PCB 1 To S/No A717392 – See Issue 14
SL17-313 Binder LED PCB 1 From S/No A717393 – See Issue 14
SL17-314 Binder Motor PCB 1 From S/No A717393 – See Issue 14
SL18-361 Cable Clamp 1 See Issue 6
SL18-368 PCB Mounting Blocks 3
SL18-380 Insulating Tape (RS494-679) in mm 75 See Issue 7. Was SL18-377 x 100mm See issue 8
SL18-383 Printed Button 1 From S/No A717393 – See Issue 14
SL20-317 Motor 140W 1
SL4-124 Cord Set UK – 2 core 1
SL4-125 Cord Set EURO – 2 core 1
SL4-129 Cord Set AUST – 2 core 1 See Issue 13
SL6-76 9MFD Capacitor 1
A55064 Edge Margin Guide Assembly (Spares) 1 Comprises D55108 and D55109
A55173A Infill Panel Assembly CB355E 1 Comprises D55133B, D55112A and D55159
A55174A Comb Opening Mechanism (Spares)
Not supplied as an assembly
1 Comprises D55076, D55077, D55078, D55079, D55091,
D55135, D55136, D55213, SL17-301 and A55173A
A55059B Die Block Assembly (Spares) 1 Comprises D55050, D55051, D55053, D55065, D55087,
To Next Page
