Page 5 of 55
ILLUSTRATED PARTS MANUAL:
FLOWLINE COMB & WIRE
BINDER RANGE
MODEL CB345E
Part No Description Qty Comments
A55216 Quadrant Gear RH 1
A55217 Quadrant Gear LH 1
BSH78 Oilite Bearing 6.5 Long 1
BSH79 Oilite Bearing AL1824 12mm long 1
D47010 13T Gear 2
D55050 Comb binder die plate 1
D55051 Comb binder stripper plate 2
D55053 Spacer block 1
D55062A Side Frame LH Electric 1 Made from D55062
D55072 Gear Shaft - Long 1
D55073 Gearbox Top Casing 1
D55074 Gearbox bottom casing 1
D55076 Comb Opening Drive Plate 1
D55077 Comb Opening Finger Plate 1
D55078 Clamp Plate 1
D55079 Comb Opening Base Plate 1
D55087 Die Support Block 1
D55091 Comb Opening Clamp Spring 2
D55100 Spacer Washer 6
D55108 Margin Adjuster Screw 1
D55109 Margin Adjuster Thumb Wheel 1
D55110E Top Cover 1
D55111C Bottom Casing 1
D55112A Document Measurer 1 Supplied as part of A55173F – See Issue 19
D55115A Side Frame RH 1 Made from D55115
D55123 Rubber Foot 2
D55125 Document Support Lid 1
D55127 Comb Opening Knob 1
D55130 Clippings Tray 1
D55131 Comb Knob Spring 2
D55133F Infill Panel 1 Supplied as part of A55173F – See Issue 19
D55135 Punch Button 1
D55136 Punch Button Spring 1
D55144 Comb Opening door shaft single knob 1
D55146 Comb Opening Bung 1
D55147 Punch Handle Bung 2
D55148 PCB Activation Cam 1
D55156 Punch Retainer 1
D55159 Document Measurer Spring 1 Supplied as part of A55173F – See Issue 19
D55162 Motor Pinion 1
D55163 Gear Shaft Short 1
D55189 Compound Gear 34/13T 1
D55190 Compound Gear 41/10T (Plastic) 1 To S/no A678190 Replaced by D55241/PLN29 – See Issue 5
D55191 Spur Gear 29T 1
D55192 Spur Gear 13T 2
D55193 Motor Support Bracket 1
D55194 Hex Spindle for gear box 1
D55195 Hexagon Spindle 1
D55198 Buffer 2
D55199 Knob retaining clip 1
D55200 Fixed Spindle 2
D55202 Rubber Foot - L Shaped 2
D55203 Rubber Foot - Front 2
