Page 6 of 55
ILLUSTRATED PARTS MANUAL:
FLOWLINE COMB & WIRE
BINDER RANGE
D55213 Punch Switch Insulation collar 1
D55214 Tie Bar 1
D55215 Compound Gear 26/10T 1
D55218 Tie Rod Bush 2
D55219 Motor insulator 1
D55220 Gear Box end plate 1
D55226 Wire - cap to PCB 1
D55227 Laser Punch Plate 1
D55236 Gear Box Shaft Retainer 1 See Issue 3
D55240 Compound Gear 41/10T (Sintered) 1 See Issue 12
D55241 Compound Gear 41/10T (Metal) 1 From S/No A678191 to A710068 See Issues 5 and 12
D55242 Thermal Fuse Assembly 1 From S/No A670764 to A694089 See Issues 4 and 11
PEG93 6 x 50mm heavy duty spirol pin 3
PLN2L 3BA plain washer 4
PLN29 M5 plain washer 1 From S/No A678191 to A710068 See Issues 5 and 12
PLN37 M9 Shim Washer 1
SCM157 M6 x 20 Taptite 4
SCM158 M5 x 16 Taptite 2
SCM159 M6 x 50 Taptite 3
SCM160 M4 x 12 Taptite 6
SCM162 M4 x 10 Screw 3
SCR718 M4 x 10 Plasform 1 Pozi Pan Screw 2 See Issue 6
SCR720 M3.5 x 10 plastech 9
SCR721 M2.5 x 8 Screw 2
SCR722 M5 x 16 Plasfix Screw 8
SCR724 M3 x 8 Screw 6
SCR725 M5 x 20 Screw 7
SHK2 3BA Shakeproof Washer 2
SL17-144 Cable Tie 6
SL17-300 Binder Motor PCB 1 To S/No A721640 – See Issue 14
SL17-301 Binder LED PCB 1 To S/No A721640 – See Issue 14
SL17-313 Binder LED PCB 1 From S/No A721641 – See Issue 14
SL17-314 Binder Motor PCB 1 From S/No A721641 – See Issue 14
SL18-361 Cable Clamp 1 See Issue 6
SL18-368 PCB Mounting Block 3
SL18-380 Insulating Tape (RS494-679) in mm 75 See Issue 7 was SL18-377 x 100mm See Issue 8
SL18-383 Printed Button 1 From S/No A721641 – See Issue 14
SL20-317 Motor 140W 1
SL4-124 Cord Set UK – 2 core 1
SL4-125 Cord Set EURO – 2 core 1
SL6-76 9MFD Capacitor 1
TRU100 E Clip 2
TRU99 Carbon Steel E Clip 5
A55064 Edge Margin Guide Assembly (Spares) 1 Comprises D55108 and D55109
A55173F Infill Panel Assembly CB345E 1 Comprises D55133F, D55112A and D55159
A55174F Comb Opening Mechanism (Spares)
Not supplied as an assembly
1 Comprises D55076, D55077, D55078, D55079, D55091,
D55135, D55136, D55213, SL17-301 and A55173F
A55179 Die Block Assembly (Spares) 1 Comprises D55050, D55051, D55053, D55087, D55100,
PEG93 and SCM159
A55222 Motor/Gearbox Assembly (Spares) 1 Comprises BSH78, BSH79, D55072, D55073, D55074,
D55162, D55163, D55189, D55191, D55193, D55215,
D55219, D55220, D55226, D55236, D55240, SCM160 (2off),
SCM162, SCR722 (4off), SCR725, SHK2, SL6-72, SL17-
144, SL20-317 and TRU99 – See Issues 11 and 12
