15
• Ensure that there are no electric lines, water or heating pipes installed at the
proposed drilling location.
• The supplied wall plugs are only suitable for mounting on concrete and stone.
Before starting the installation, please check your installation location carefully for
its suitability for the plugs.
The assembly material used must be suitable for the respective location. If in doubt,
consult a professional.
Tripod screws
Bracket support rod
Bracket fixing screws
Screws
Wall plugs
Drill holes
Components
Mounting the Screw Mount
CAUTION
Required Tools
• Drill
• 6 mm masonry/concrete drill bit
• Phillips head screwdriver
