DP3800RF PARTS LIST
ORDER ONLY BY MODEL NUMBER AND PART NUMBER
ID NO. Description Size Q’ty ID NO. Description Size Q’ty
0607 SWITCH BOX 1 0KPX HEX. NUT 1/2*20UNF T=6.5 1
2457 FLAT WASHER 1 0KQX NUT M6*1.0 T=6 2
04Q4 STICKER 1 0KSM STRAIN RELIEF 1
056T COLUNM ASS’Y 1 0KSQ STRAIN RELIEF 2
05UE BASE 1 0KYN LEAD WIRE ASS’Y 1
05UW WORM 1 0LRT ROCKER SWITCH 1
05UX CRANK HANDLE ASS’Y 1 0SH0 CHUCK KEY 1
05VN TABLE 1 0VJK PLATE SPRING ASS’Y 1
05VT RACK RING ASS’Y 1 21HP HUB 1
05WJ HANDLE SHIFTER 1 22A4 LOCKING CABLE TIE 1
05WL MOTOR BAR SHIFTER ASS’Y 1 23MS COVER 1
05WN MOTOR ROD 1 23N1 CUSHION 1
05WR SHIFTER BOLT M10*1.5-33 2 25Q0 WARNING LABEL 2
05WV MOTOR BASE 1 27EY FEED SHAFT ASS’Y 1
05X9 HANDLE BAR 3 27QB TABLE LOCK HANDLE M10*1.5-25 6# 1
05XK SCALE RING 1 27QC COLUMN LOCK HANDLE M12*1.75-35 6# 1
05Y2 QUILL SET SCREW 1 28NX GRIPE 6# 3
05YN DRIVING SLEEVE ASS’Y 1 28SZ TABLE BRACKET ASS’Y 1
05YS PULLEY SET NUT 1 2CXB SET BOLT 2
05Z2 WEDGE SHIFTER 1 2D18 LASER ASS’Y 2
061R CHUCK KEY HOLDER 6# 1 2JPC LABEL 1
061Y MOTOR ROD 1 2KVN PARALLEL KEY 1
06SV CORD-CLAMP 1 2U85 CLAMP-CORD 3
0HY8 DRILLING ARBOR 1 2VVK PLATE COVER 6# 1
0J28 CHUCK & KEY 1 2VVL COVER 6# 2
0J3M HEX. WRENCH 1 2VVU SWITCH COVER 1
0J3Q HEX WRENCH 1 2VWD LEAD WIRE ASS’Y 1
0J3R WRENCH HEX. 1 2WA9 PLUNGER HOUSING 1
0J4M FLAT WASHER φ12*21-1 1 2WAQ LOCKING RING 1
0J4Q FLAT WASHER φ12*21-2 1 2WAR ADJUSTING NUT 1
0J7F FLAT WASHER 5/16*7/8-5/64 4 2WK0 COMPRESSION SPRING 1
0J8F FLAT WASHER φ8.5*22-3 4 2X1V LAMP 1
0J9M SPRING WASHER φ1/2” 3 2X1W CONTROLLER ASS’Y 1
0JAF EXTERNAL TOOTH LOCK WASHER φ5 2 2X23 ROCKER SWITCH 1
0JCM SPRING PIN 2 2X4U HEAD 1
0JKC V-BELT 1 2X4Z NUT
1/2”-20UNF-2B D=φ25 H=8
1
0JKH V-BELT 1 2X50 PULLEY COVER ASS’Y 1
0JQ0 HEX. HD. BOLT M10*1.5-40 4 2XB7 POWER CABLE COVER 1
0JUY HEX. SOC. HD. CAP BOLT M8*1.25-35 1 2XB8 LAMP SET 1
0JXL HEX. SOC. SET SCREW M10*1.5-12 2 2XHN SPINDLE ASS’Y 1
0K17 HEX. HD. SCREW AND WASHER M8*1.25-20 4 2XK6 SET BOLT ASS’Y 1
0K2A HEX.SOCKET HD.CAP SCREWS M6*1.0-25 2 34UD SET RING 1
0K7K CR. RE. ROUND WASHER HD. SCREW M6*1.0-12 5 34UN SPINDLE PULLEY 1
0K94 CR. RE. TRUSS HD. TAPPING SCREW M5*12-16 2 365A RACK 1
0K9X DRIVE SCREW φ2.3-5 4 365B SET RING ASS’Y 1
0KA9 CR.RE. PAN HD. TAPPING SCREW M3*24-10 1 365K MOTOR PULLEY ASS’Y 1
0KDJ CR. RE. PAN HD. SCREW M5*0.8-12 2 365L CENTER PULLEY ASS’Y 1
0KDK CR. RE. PAN HD. SCREW M5*0.8-16 3 36EF INSTRUCTION MANUAL 1
0KDR CR. RE. PAN HD. SCREW M5*0.8-10 3 36J9 TRADEMARK LABEL 1
0KDU CR. RE. PAN HD. SCREW M6*1.0-12 5 36JF WARNING LABEL 1
0KFF CR. RE. PAN HD. SCREW M5*0.8-8 2 36JG CAP. LABEL 1
0KMU HEX. NUT M10*1.5 T=8 1 36JH SCALE 1
0KMV HEX. NUT M10*1.5 T=8 1 36QW MOTOR ASS’Y 1
0KMX HEX. NUT M12*1.75 T=10 2 37CP POWER CABLE 1
0KMY HEX. NUT M8*1.25 T=6.5 4 7401 CAUTION LABEL 2
0KPW HEX. NUT 1/2*20UNF T=8 2
