3
15.Never turn your drill press on before
clearing the table of all objects (tools,
scraps of wood, etc.).16.Before starting
the operation, jog the motor switch to
make sure the drill bit does not wobble or
vibrate.
17.Let the spindle reach full speed before
starting to drill. if your drill press makes
an unfamiliar noise or if it vibrates
excessively, stop immediately, turn the
drill press off and unplug. do not restart
the unit until the problem is corrected.
18.Do not perform layout assembly or set up
work on the table while the drill press is
in operation.
19.Use the recommended speed for any
drill press accessory and for different
workpiece material. read the instructions
that come with the accessory.
20.When drilling large diameter holes,
clamp the workpiece rmly to the table.
otherwise, the bit may grab and spin the
workpiece at high speeds. do not use y
cutters or multiple-part hole cutters, as
they can come apart or become
unbalanced in use.
21.Make sure the spindle has come to
a complete stop before touching the
workpiece.
22.To avoid injury from accidental starting,
always turn the switch “off” and unplug
the drill press before installing or
removing any accessory or attachment or
making any adjustment.
23.Use only the self-ejecting type chuck key
as provided with the drill press.
SYMBOLS
V ……....volts A ….....…..........amperes
Hz ….….hertz W ...........................watts
min …....minutes ~ .......alternating current
h …........hours ..Class II Construction
I ………..ON O ….…....................OFF
min
-1
…......revolutions per minute
ENVIRONMENTAL PROTECTION
Recycle unwanted materials instead
of disposing of them as waste.
All tools, hoses and packaging
should be sorted, taken to the local
recycling centre and disposed
of in an environmentally safe way. Do
not dispose of electrical appliances as
unsorted municipal waste, use separate
collection facilities. Contact your local
government for information regarding the
collection systems available. If electrical
appliances are disposed of in landlls or
dumps, hazardous substances can leak
into the groundwater and get into the food
chain, damaging your health and well-
being. When replacing old appliances with
new once, the retailer is legally obligated to
take back your old appliance for disposal
at least for free of charge. Disposal of
discarded material shall be in accordance
with local environmental regulations.
Installation
Know Your Drill Press (Fig. 1)
1. Laser On/Off Switch
2. Lamp (40 W bulb not included)
3. On/Off Switch
4. Chuck Key Holder
5. Chuck
6. Rack Ring
7. Table
8. Table Lock Handle
9. Base
10. Column
11. Table Bracket
12. Table Crank Handle
13. Rack
14. Feed Handle
15. Laser Guide
16. Motor
17. Belt Tension Handle
18. Pulley Cover
Keep hands away from blade:
Failure to keep your hands
away from the blade will result in
serious personal injury.
WARNING! To reduce the risk of
injury, user must read instruction
manual.
Wear safety goggles.
Wear ear protection.
Wear a breathing mask.
