10.2 Housing Dimensions
10.2.1 IndraControl VDP 16.3
VDP 16.3 standard version
Irrespective of the design of the VDP 16.3 standard variants with keys (M-keys)
or touch screen the front panel width is 350 mm and the height is 290 mm. All
values in the illustrations are given in mm.
290
350
Fig. 10-1: Dimensions: Front panel of the VDP 16.3DB
VDP 16.3, VDP 40.3, VDP 60.3
Bosch Rexroth AG
Assembly, Disassembly and Electrical Installation
DOK-SUPPL*-VDP*XX.3***-IT03-EN-P
17/53
