Ruijie RG-NBS3100 Series Switches Hardware Installation and Reference Guide Product Installation
22
Step 2: Use the supplied M6 screws and cage nuts to securely attach the mounting brackets to the rack, as shown in
Figure 3-3, Figure 3-4, Figure 3-5, and Figure 3-6.
Figure 3-3 Attaching the Brackets to the Rack (8-Port Switch)
Figure 3-4 Attaching the Brackets to the Rack (8-Port Switch)
Figure 3-5 Attaching the Brackets to the Rack (24-Port Switch)
