Reznor RDH Series User Manual

1307SDH_RDH--EN,page 5/32
CONFIGURATIONS – DIMENSIONS - CLEARANCES
Figure 2.1 : SDH model - Standard
GF
C1
N100
E1
B
Suspension Points
A1
Suspension Points
dia 11
dia in
OMO
LP
J
K
UQR
TS
Z1
min 150
min 200
min 750
5
234
6
SIDE VIEW
FRONT VIEW
TOP VIEW REAR VIEW
1
SDHA1BC1E1FGJKLMNOPQRSTUZ1Øin
025 1584 806 1454 1654 140 573 190 840 212 600 753 120 300 502 270 380 81 68 1800 102
030 1584 1060 1454 1654 140 573 190 1094 212 700 753 197 300 756 270 380 81 68 1800 102
035 1584 1060 1454 1654 140 573 190 1094 212 700 753 197 300 756 270 380 81 68 1800 102
043
1852 806 1722 1922 140 841 190 840 229 600 988 120 500 502 270 615 81 68 2500 102
055 1852 806 1722 1922 225 756 190 840 229 600 988 120 500 502 270 615 81 68 2500 132
073 1852 1234 1722 1922 225 764 240 1268 229 1000 988 134 500 629 365 615 81 274 2500 132
100 1852 1434 1722 1922 225 764 240 1468 229 1200 988 134 500 820 373 615 81 275 2500 132
4
IMPORTANT : Always respect a minimum clearance of 600mm when open intake opening (inlet side)
1. Combustion inlet air
2. Combustion outlet air
3. Electrical connections
4. Gas connection
5. Service panel
6. Suspension points
All dimensions are in mm.
Tolerance all dimensions 3mm
